Equipment Features
1. Wide range of applicable auxiliary materials: Suitable for bonding adhesives, foam, conductive cloth, heat sinks, graphite sheets, protective films, Mylar sheets, and other precision auxiliary materials.
2. Multi-strip, multi-station structure: Loading and unloading do not disrupt cycle time, resulting in high throughput and labor savings.
3. High degree of automation: Supports feeder feeding, automatic film tearing, waste material rewinding, CCD inspection, and robotic loading and unloading, reducing manual intervention.
4. Sturdy structure, low failure rate: High-rigidity frame + precision transmission ensures consistent accuracy over long-term operation, simple maintenance, and long service life.
5. Quick product changeover, strong versatility: Formula parameters can be stored and recalled with one click; fixture replacement is simple, suitable for multi-variety, small-batch, high-frequency production changes.
Technical Specifications
| Project | Specifications |
| Equipment Model | MY-VALM03 |
| Equipment Function | The equipment is mainly used for attaching auxiliary materials (labels, conductive cloth, foam) |
| Applicable Sizes | L: 80mm~200mm x W: 40mm~130mm |
| Adhesion Accuracy | ±0.1mm, CPK≥1.33 |
| Alignment Method | Mechanical Alignment + CCD Vision Guided Positioning |
| Equipment Dimensions | L2050 x W1960 x H1800 |
| Power Supply Voltage | AC380V 50/60HZ |
| Air Supply Requirements | 0.6MPa (6Kgf/cm2) |
| Equipment Capacity | ≤9S/PCS |
| Lamination Method | Cylinder Lamination |
| Other Main Functions | Automatic barcode scanning, automated loading and unloading |
For 3C, new energy, automotive electronics, medical devices, aerospace enterprises, we provide exclusive customized solutions and
equipment based on their unique demands and specific problems.
